[Java High Salary Interview Collection] Day3, graphic HashMap high-frequency interview and the underlying implementation architecture!

Welcome friends to subscribe to my new column " Java High Salary Interview Book", here I will share with you the core test points and techniques commonly seen in Java interviews, and help everyone on the road to Java learning!

HashMap high-frequency interview questions

1. What is the relationship between the Map interface and the List interface?

2. What are the commonly used implementation classes for Map?

3. Please explain the put process of HashMap?

4. In what order is the data stored in the linked list?

5. How is the Hash(key) method implemented?

6. Why is the capacity of HashMap always a multiple of 2?

7. How to resolve Hash conflicts?

8. How does HashMap expand?

9. How are the elements stored after expansion?

10. Comparison of the implementation of HashMap between JDK1.7 and JDK1.8


Hello, how are you, I am the little gray ape ! A programmer who can write bugs !

Everyone has heard of the Map interface, right? It is a common way to store key-value pairs in Java. I believe that you should not be unfamiliar with the HashMap. When it comes to HashMap, my friends who want to know a little bit should say: This is For storing key-value pairs, the storage method is in the form of an array plus a linked list. But do you know how to store it and how its underlying architecture is implemented?

Maybe a lot of friends should talk about it. I only need to know how to use it. I don’t need to know its underlying implementation. But in fact, on the contrary, it’s not enough to know how to use it, and it’s in the Java development interview. , Questions and inspections of the underlying implementation of HashMap are already commonplace. So today I will analyze with you the detailed use of the Map interface and how the bottom layer of HashMap is implemented?

Friends slowly look down, you will definitely be rewarded after reading it!

1. What is the relationship between the Map interface and the List interface?

For this question, if we have to say what kind of relationship exists between these two interfaces, then there is only one, and they are all sets. Store data. In other cases, the connection between the Map interface and the List interface is actually not that great. Why do you say that?

Let’s look at the List interface first. I mentioned the List interface before, "[Java High Salary Interview Collection] Day2, talk about the implementation of the List interface? 》 , it is inherited from Collection interface, is a sub-interface of Collection interface , it is only used for single-column storage of data. The inheritance relationship is as follows:

The Map interface is a top-level interface , which contains many different implementation classes below. It is used to store key-value pairs (key:value) . The implementation relationship is as follows:

So don't confuse the relationship and use of the Map interface and the List interface!

2. What are the commonly used implementation classes for Map?

We have already learned about the inheritance structure of Map above, and we have also looked at many of the different implementation classes, many of which are familiar to us, such as HashMap, TreeMap and HashTable. During the interview, the interviewer often asks what are the commonly used implementation classes under the Map interface and their functions. Then we will briefly introduce and analyze these interfaces.

HashMap: As mentioned above, the underlying implementation of HashMap is in the form of array + linked list + red-black tree . At the same time, the default initial capacity of its array is 16, the expansion factor is 0.75, and the expansion is twice as large each time. In other words, whenever the storage capacity in our array reaches 75%, we need to double the capacity of the array.

HashTable: The HashTable interface is thread-safe, but it was used a long time ago, and now it almost belongs to a legacy class, and it is not recommended to use it in development.

ConcurrentHashMap: This is a thread-safe Map implementation class that is currently used more frequently. Before 1.7, the segmented lock mechanism was used to achieve thread safety . But after 1.8, use the synchronized keyword to achieve thread safety .

Among them, HashMap surveys and questions are the most frequent in the interview, which is also the most in-depth understanding and mastery in daily development. So next, I will mainly analyze the implementation principle of HashMap and the frequently asked questions in the interview with you in detail.

3. Please explain the put process of HashMap?

We know that HaahMap uses the put method for data storage. There are two parameters, key and value. So how is this key-value pair stored? Let's analyze it next.

In the HashMap, an array + linked list is used. The upper layer of the HashMap uses an array to store the "same" keys, and the lower layer uses a linked list to link and store the corresponding keys and values.

Note: The same thing mentioned here does not necessarily mean that the value of the key is the same, but that there is a certain characteristic that is the same. We will continue to look down on the specific characteristics!

HashMap calculates the corresponding array subscript of the value to be stored according to the key. If there is no element at the position of the corresponding array subscript, then the stored element is stored, but if there is already an element at that position, then this We need to use the linked list storage we mentioned above, and store the data sequentially downwards in the order of storage of the linked list. This is the simple process of put, and the storage result is as follows:

But sometimes we store a lot of data, so if we always use the form of linked list for data storage, it may cause the length of our linked list to be very large, so whether it is deleting or inserting is very troublesome, so What should we do in this situation?

This involves the process of "treeing" and "chaining" when storing data in a linked list. So what is "treeing" and "chaining"?

When we are storing key-value pairs, if we store too much data under the same array subscript, it will cause our linked list to be too long, which will lead to troublesome deletion and insertion operations, so in java It stipulates that when the length of the linked list is greater than 8, we will "tree" the linked list and convert it into a red-black tree (a binary tree where the value of the left node is less than the root node, and the value of the right node is greater than the root node) , So that when we search for elements, it is similar to binary search, and the search efficiency will be greatly increased.

But when we delete some of the nodes, the length of the linked list is no longer greater than 8. What should we do at this time? Is it necessary to quickly transform the red-black tree into the form of a linked list? In fact, it is not. Only when the length of the linked list is less than 6, we will re-convert the red-black tree into a linked list. This process is called "chaining".

The process diagram is as follows:

So why do we need to "tree" when the length is 8 and "chain" when the length is less than 6? Why not just "chain" when the length is less than 8?

The main reason is: when an element is deleted and the length of the linked list is less than 8, it will be directly "chained", and when an element is added and the length is equal to 8, it will be "treeed" again, so that the "chain" is repeated. The operations of "modification" and "treeization" are particularly time-consuming and cumbersome. Therefore, the program stipulates that "treeing" is performed only when the length of the linked list is greater than or equal to 8, and "chaining" is performed when the length is less than 6. The two thresholds of 8 treeing and 6 chaining are expected to be kept in mind. !

4. In what order is the data stored in the linked list?

We now know how the elements in the HashMap are stored, but sometimes the interviewer may ask us, in the HashMap, are the elements stored in the linked list stored at the head node or at the tail node?

We need to know about the storage of linked list elements in HashMap.

It was inserted at the head node before JDK1.7 and at the tail node after JDK1.8.

5. How is the Hash(key) method implemented?

We now know how the elements in the HashMap are stored, so now how should we calculate the corresponding array subscript based on the key value?

We know that the initial capacity of HashMap is 16 bits. For the initial 16 data bits, if the data is calculated and stored according to the value of the key, the simplest method is generally to obtain an int value based on the key value. The method is:

int hashCode = key.hashCode()
Then perform the remainder operation on the obtained hashCode and 16,
hashCode% 16 = 0~15

The subscripts obtained in this way are always 0-15. This is also the most primitive way to calculate hash(key).

However, in actual situations, the hash (key) calculated by this method is not optimal, the elements stored in the array are not the most scattered, and it is actually very inconvenient to perform remainder operations in the computer.

So in order to calculate the results as discrete as possible, the most commonly used method for calculating the array index is: first calculate a hashCode according to the value of the key, and perform the exclusive OR operation on the high 18-bit binary and the low 18-bit binary of the hashCode to obtain the result Then it is ANDed with the current array length minus one. Finally get an array subscript, the process is as follows:

int hashCode = key.hashCode()
int hash = hash(key) = high 16 bits of key.hashCode() ^ low 16 bits & (n-1) where n is the current array length

At the same time, I would like to remind one thing here.

The calculation of hash(key) is slightly different between JDK1.7 and JDK1.8

When JDK1.8, the calculation of hash(key) was disturbed twice

In JDK1.7, computing hash(key) performed nine perturbations, which are four bitwise operations and five exclusive-or operations.

The disturbance may be understood as the number of operations

The above is the implementation process of the Hash(key) method.

6. Why is the capacity of HashMap always a multiple of 2?

The reason why the capacity of HashMap has always been a multiple of 2 is actually related to the hash(key) algorithm mentioned above.

The reason is that only when the value of (n-1) participating in the hash(key) algorithm is as much as possible, the value obtained is discrete. If our current array length is 16, the binary representation is 10000, and the value of n-1 is 01111, so that the value of n-1 is 1 as much as possible, and the same is true for other values ​​that are multiples of 2 after subtracting 1.

So only when the capacity length of the array is a multiple of 2, the calculated hash(key) value may be relatively discrete.

7. How to resolve Hash conflicts?

What is Hash conflict? That is, when I calculate a certain array subscript, there are already elements stored on the subscript. This is called a Hash conflict. Obviously, if our algorithm for calculating the array subscript is not good enough, it is easy to accumulate the stored data. Above the same subscript, causing too many Hash conflicts.

So how to resolve hash conflicts?

The most important thing to solve is to make the array subscript calculated by the stored key as discrete as possible, that is, the hash (key) is required to be optimized as much as possible, and the length of the array is a multiple of 2. This is the main solution to the Hash conflict.

For details, you can view the underlying source code of the key parts of HashMap below:

The underlying implementation of Hash(key)

    /**     * Applies a supplemental hash function to a given hashCode, which     * defends against poor quality hash functions.  This is critical     * because HashMap uses power-of-two length hash tables, that     * otherwise encounter collisions for hashCodes that do not differ     * in lower bits. Note: Null keys always map to hash 0, thus index 0.     */    static int hash(int h) {        // This function ensures that hashCodes that differ only by        // constant multiples at each bit position have a bounded        // number of collisions (approximately 8 at default load factor).        h ^= (h >>> 20) ^ (h >>> 12);        return h ^ (h >>> 7) ^ (h >>> 4);    }

Low-level implementation of put(key, value) method

    /**     * Associates the specified value with the specified key in this map.     * If the map previously contained a mapping for the key, the old     * value is replaced.     *     * @param key key with which the specified value is to be associated     * @param value value to be associated with the specified key     * @return the previous value associated with <tt>key</tt>, or     *         <tt>null</tt> if there was no mapping for <tt>key</tt>.     *         (A <tt>null</tt> return can also indicate that the map     *         previously associated <tt>null</tt> with <tt>key</tt>.)     */    public V put(K key, V value) {        if (key == null)            return putForNullKey(value);        int hash = hash(key.hashCode());        int i = indexFor(hash, table.length);        for (Entry<K,V> e = table[i]; e != null; e = e.next) {            Object k;            if (e.hash == hash && ((k = e.key) == key || key.equals(k))) {                V oldValue = e.value;                e.value = value;                e.recordAccess(this);                return oldValue;            }        }         modCount++;        addEntry(hash, key, value, i);        return null;    }

8. How does HashMap expand?

We mentioned above that the initial capacity of the HashMap array is 16, but it is obvious that 16 storage bits are obviously not enough, so how should the HashMap be expanded?

Here you need to use a parameter called "Expansion Factor", the size of "Expansion Factor" in HashMap is 0.75,

As we mentioned above, for an array with an initial length of 16, when the length of the data stored in it is equal to 16*0.75=12. The array elements will be expanded. The expanded capacity is twice the original array capacity, which is currently 15 words, and then the expansion is to expand the capacity by 32 data bits. ??????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????

9. How are the elements stored after expansion?

We know that after the HashMap array is expanded, the length of the array is increased, so at this time, the newly expanded part is empty. But should we leave the following data bits empty at this time? Obviously it is impossible, this will cause a lot of waste of memory.

Therefore, after the expansion of the HashMap array, the data elements stored in the original HashMap array will be re-allocated, and the elements will be stored in the new array again. In order to make full use of the array space.

10. Comparison of the implementation of HashMap between JDK1.7 and JDK1.8

The implementation of HashMap in JDK1.7 and JDK1.8 is slightly different. Finally, we analyze and compare the differences in the implementation of HashMap between JDK1.7 and JDK1.8 based on the above explanation.

(1) The underlying data structure is different

In the put process of HashMap, there is no concept of red-black tree in JDK1.7, it is directly stored in linked list. After JDK1.8, the concept of red-black tree was introduced to optimize storage and search.

(2) The way to insert the linked list is different

In the process of HashMap inserting elements into the linked list, JDK1.7 is inserted at the head node of the table, and after JDK1.8 it is inserted at the end node.

(3) The calculation method of Hash(key) is different

In the calculation of Hash(key), JDK1.7 performed nine perturbations, including four bit operations and five exclusive OR operations. After JDK1.8, only two perturbations were performed.

(4) The calculation method of the storage location of the expanded data is different

In the rearrangement of the stored data after expansion, JDK1.7 scrambles the location of all data, and then recalculates it based on the hash (key). After JDK1.8, the original data subscript is doubled. For loops. The calculated new subscript position can only be the original subscript position or the original subscript position plus the original capacity position.

Well, the process of the underlying implementation of the Map interface and HashMap, as well as the core questions referred to in the interview, will be analyzed with everyone here!
